T&R<br>DMO600

T&R
DMO600

Micróhmetro, digital, 600 Adc



The DMO600 is ideal to measure busbar joint resistance. It is suited to all low resistance measurements on power systems.

It is particularly suited to measuring contact resistances on substation circuit breakers, isolators and grounding equipment.

The unit has a powerful output capable of driving 600A through 20m output leads to reach the contacts of even the largest circuit breakers.

It requires 90-265Vac 3800VA max and outputs 10-600ADC 5V.

  • 90-264V supply voltage;
  • Output: 10-600ADC 5V
  • Resistance measurement: 0.1 Ohm-5 Ohm
  • 5V 10-600A pre-settable current;
  • Set test current to 100A, 300A and 600A;
  • USB data storage (CSV Format);
  • USB keyboard;
Categoría: Etiqueta:
